bolted type cement silos

Field of application: JX (Sheet cement tank)The schistose sheet cement silo equipment information and product description: Our company provides all kinds of volume and tonnage of sheet cement silo...
WhatsApp:0086-18437125333
Equipment introduction
JX (Sheet cement tank)The schistose sheet cement silo equipment information and product description: Our company provides all kinds of volume and  tonnage of sheet cement  silo, cement silo  suitable for store grain, cement, fly ash and all kinds of bulk material.The tank is equipped with a material level system that can display the position of the material. The schistose sheet cement silo and slice cement silo are solve export loading, make barrels on-site, transfer on the construction site, ultra-high-wide transportation many difficult problem. Cement silo (cement tank) are accordance with industry standards. Discharge height  have 1.96 meters, 4.2 meters, Accept OEM as the customers  requirements.
flaky cement bin
Technical Parameters
Model capacity(T) diameter(m) height(m)  Leg height (m) weight(t) Mixer Model

Type of screw conveyer

JX-50 50 3 6.5 2/4.5 2.7 JS500 LSY180
JX-60 60 3 7.8 2/4.5 3.2 JS500 LSY180
JX-80 80 3 9 2/4.5 3.8 JS750 LSY219
JX-100 100 3 12.8 2/4.5 4.2 JS1000 LSY273
JX-150 150 3.3 13.5 2/4.5 5.8 JS1500 LSY325
Model capacity(T) diameter(m) height(m)
JX-50 50 3 6.5
JX-60 60 3 7.8
JX-80 80 3 9
JX-100 100 3 12.8
JX-150 150 3.3 13.5
Product advantages
1.Dusting system: Top of cement silo is equipped with electric dusting device, which can effectively adsorb suspended particles in the silo and reduce the surrounding environment pollution.
2.Breaking arch device: The cement silo have  equipped with an air-blast arch-breaking device at the lower cone.  The small electromagnetic directional valve in the air control box is used to control the release of compressed air to break the arch of cement and various powders to avoid the powder heap and Cause blockage.
